کولر ترموالکتریک TEC1-12709

Description:
The TEC1-12709 Peltier Module is a popular and versatile thermoelectric device used for heating and cooling applications. This module is based on the Peltier effect, which allows it to transfer heat by applying a voltage across its two ceramic plates. The TEC1-12709 module features 127 semiconductor couples that are connected electrically in series and thermally in parallel. This configuration provides efficient heat transfer and temperature control capabilities. The module is designed to operate with a maximum voltage of 12V and a maximum current of 9A, making it suitable for a wide range of power sources. The TEC1-12709 Peltier Module is commonly used in various applications, including refrigeration, temperature regulation in electronic devices, and thermal management in scientific and industrial equipment. Its compact size and robust construction make it easy to integrate into existing systems, and its reliable performance ensures effective heat exchange. Whether you need to cool electronic components or create a temperature-controlled environment, the TEC1-12709 Peltier Module is a reliable choice for efficient and precise thermal management.

Features:
Model: TEC1-12709
Rated voltage: 12V
Rated Current: 9A
Power: 82W
Maximum temperature difference : 68 degrees Celsius
Cable length: 30cm
Material: Plastic + ceramics + silicon
Size: 40mm x 40mm x 3.4mm

Note :
These devices must be used in combination with a heat sink to prevent it from burning
It should Cover with thermal paste when used
